Ros MCP Server

Overview

The ROS MCP Server is designed to support robots in performing complex tasks and adapting effectively to various environments by providing a set of functions that transform natural language commands, entered by a user through an LLM, into ROS commands for robot control. Furthermore, by utilizing rosbridge, it is configured to operate with both ROS and ROS2 systems, and its WebSocket-based communication enables broad applicability across diverse platforms.

Research based on this project can be found in the video linked below.

• An Efficient Robot Control Framework Using the Model Context Protocol

Supported Types

• geometry_msgs/Twist
• sensor_msgs/Image

Installation

Installing via Smithery

To install ros-mcp-server for Claude Desktop automatically via Smithery:

npx -y @smithery/cli install @lpigeon/ros-mcp-server --client claude

Installing Locally

uv Installation

• To install uv, you can use the following command:

curl -LsSf https://astral.sh/uv/install.sh | sh

or

pip install uv

• Create virtual environment and activate it (Optional)

uv venv
source .venv/bin/activate

MCP Server Configuration

Set MCP setting to mcp.json.

"ros-mcp-server": {
  "command": "uv",
  "args": [
    "--directory",
    "/ABSOLUTE/PATH/TO/PARENT/FOLDER/ros-mcp-server",,
    "run",
    "server.py"
  ]
}

If you use Claude Desktop, you can find mcp.json using the following command:

• MacOS/Linux

code ~/Library/Application\ Support/Claude/claude_desktop_config.json

• Windows

code $env:AppData\Claude\claude_desktop_config.json

MCP Functions

get_topics

• Purpose: Retrieves the list of available topics from the robot's ROS system.
• Returns: List of topics (List[Any])

pub_twist

• Purpose: Sends movement commands to the robot by setting linear and angular velocities.
• Parameters:
  • linear: Linear velocity (List[Any])
  • angular: Angular velocity (List[Any])

pub_twist_seq

• Purpose: Sends a sequence of movement commands to the robot, allowing for multi-step motion control.
• Parameters:
  • linear: List of linear velocities (List[Any])
  • angular: List of angular velocities (List[Any])
  • duration: List of durations for each step (List[Any])

sub_image

• Purpose: Receive images from the robot's point of view or of the surrounding environment.
• Parameters:
  • save_path: By default, the image is saved to the Downloads folder.

How To Use

1. Set IP and Port to connect rosbridge.

• Open server.py and change your LOCAL_IP, ROSBRIDGE_IP and ROSBRIDGE_PORT. (ROSBRIDGE_PORT's default value is 9090)

2. Run rosbridge server.

ROS 1

roslaunch rosbridge_server rosbridge_websocket.launch

ROS 2

ros2 launch rosbridge_server rosbridge_websocket_launch.xml

3. Run any AI system that has imported ros-mcp-server.

4. Type "Make the robot move forward.".

5. Check rosbridge_server and ros topic.

• rosbridge_server

• ros topic

Simulation Test

MCP-based control using the MOCA mobile manipulator within the NVIDIA Isaac Sim simulation environment.
